Armour Scan

Fully Programmable Mini-Terminal LCD Pinpad

  • 3 Year “No Fault” Replacement Warranty
  • Spill-Proof Case enclosed in Non-Slip Body Armour - Multiple Color Options
  • “Yank-Proof” Cable / USB port Protector System
  • Small Footprint
  • Required FDA Braille Keys
  • Adjustable Volume
  • Masking/Unmasking Controls
  • Compatible with your POS Software

Specifications

  • Number of Keys - 15 Keys (3x5)
  • USB Interface - USB 2.0 / 1.1 Full Speed
  • Power Supply - 5v DC, 110mA (max), USB Bus Powered
  • LCD Type - 2 Line x 16 Character STN LCD Display
  • LCD Backlight - LED Backlight
  • Barcode Scanner - Front Mounted, Visible RED Beam With CCD Image Sensor. Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN, Code 93, UCC/EAN-128, GS1 Databar
  • Dimensions - 17.1 x 9.5 x 3.5 cm, 6.75 x 3.75 x 1.375 in. (L x W x H)
  • Weight - 9 oz / 13 oz with Protective Case
  • Operating Temperature - 0 to 60 Degrees C (32 to 140Degrees F)
  • Operating Humidity - 5% to 90% Non-Condensing
  • FCC Rating - Class B Device

Request a Quote

Our experienced technicians can help you determine the best solution based on your needs and budget.
